A shots from last year vegetation point cloud mapping in Brandenburg. Strong Hotspot-Effect visible with easily visible shadow projection of the quadrocopter shape on the tree crown texture. Nice example of this direct back-reflection effect on vegetation (crown surface in this example), although you can also clearly see the same effect on the grassland vegetation in the neighborhood of the tree crown.
Die unterschiedlichen Datensätze der Befliegungen für die Grabungen auf dem Alten Gleisberg und bei Kuckenburg in 2017 sind nun vollständig an das Seminar für Ur- und Frühgeschichtliche Archäologie übergeben worden. Die abgeleiteten Datenlayer umfassen jeweils Punktwolkenmodelle im LAS Format, DSM (Digitales Oberflächenmodell ohne Normalisierung) und jeweils das Orthomosaik mit Georeferenzierung von der Befliegung. Alle Daten wurden nach UTM32 WGS84 georeferenziert. Insgesamt wurden Daten im Umfang von über 100 GB verarbeitet. Die Befliegungen fanden jeweils in drei verschiedenen Flughöhen statt und liefern nun nach der Berechnung der Punktwolke eine cm-genaue Darstellung der Grabungsflächen bzw. deren 3D-Volumenwerte.
Die präzise Verarbeitung und Georeferenzierung der Copter Daten von diesen Befliegungen ist durchaus aufwändig. Jedoch methodisch eher unproblematisch schritt. Schwieriger wird die präzise Punktwolkenfusion aus verschiedenen Grabungen werden. Hier ist die absolute Georeferenzierungsgenauigkeit entscheidend.
Abb. 1: Grabungsareal der Kuckenburg-Befliegung vom September 2017 (Tiefbefliegung mit der Phantom 4 Pro, Punktdatenmodell mit 70 Mio Punkten abgeleitet aus einem Bilddatenpool von 250 Fotos).
Abb. 2: Grabungsareal der Kuckenburg-Befliegung – Hochbefliegung.
Abb. 3. Befliegung am alten Gleisberg – in dieser Abbildung: das Punktmodell der Hochbefliegung vom August 2017.
Abb. 4. Befliegung am Alten Gleisberg – Detailbefliegung des Grabungsareals.
169. DVW-Seminar “UAV 2018 – Vermessung mit unbemannten Flugsystemen” :
Struktur Retreat des Lehrstuhls für Fernerkundung im Rittergut Positz (10.-11.1.2018). 2 lange Tage mit Präsentationen, Diskussionen, viel Planungen für 2018, Gruppenbild vom Copter ;).
Some results from DGPS point measurements with a Stonex S9III GNSS DGPS receiver indicate an offset of 1.5-3 m to the Phantom 4 Pro ortho mosaic images. The relative accuracy is however much better. The Phantom 4 Pro derived ortho mosaic (without reference points) has a standard deviation of 0.31 to 0.36 m.
When comparing the overall positional accuracy of the reference points its surprising that the UTM coordinates that come directly from the Phantom 4 Pro are not far off: I measured 12 DGPS points and found that the offset is between 150 cm and 290cm (compare with Fig. 6).
RMSE between the Stonex S9III DGPS (SAPOS) measured points and the DJI Phantom 4 pro POI mode ortho image mosaic measured points is 1,98 m (stdev 0,31 m) and the RMSE between the Stonex Points and P4P NADIR mode ortho image mosaic measured points is 2,95 m (stdev 0,36 m). The difference is clearly also depending on overall atmosphere conditions and Stonex DGPS accuracy.
Fig. Comparison of measured DGPS Stonex GNSS points with in-Copter derived GPS geometry in POI ortho mosaic and with Nadir ortho mosaic processed in Agisoft in September 2017.
For those not too familiar with the ICAO maps – its nice to have this overview at hand sometimes:
The full PDF is available here:
https://www.flightplanner.de/legenden/ICAO-D.htm
Some tests using the DJI GS Pro (Ground Station) software for automatic flight programming with the Phantom 4 Pro.
New flight campaign at the Kuckenburg spot (Sachsen-Anhalt) finished with two different flight altitudes using DJI GS Pro – mapping the open archaeological excavation site of medieval church now in September 2017. This worked flawless – the only problem: you kind of need a mobile connection with your iPad. Since DJI GS is an iPad-only software I used a hotspot from the iPhone to bring the iPad online. Its not perfect but it works. Overall I find DJI GS Pro to be more easy to program and to setup than Drone Deploy. The interface has more option to setup – so it is at first more complex but it integrates into the DJI Go App and so far my impression is that it is not giving these unexplained copter start problems that Drone Deploy sometimes showed. GS also seems to be less integrated into a subscription model and looks like a standalone software solution – though a DJI account is needed. I havnt tested capturing DNGs. Its not a direct option as far as I can see – this could be a limitation. You can easily modify exposure times and f-stop numbers even when flying to geht sharper shots. There is however so far no option to switch from JPEG to DNG. As this is usually only limited by bandwidth it could be an option that is available when you decrease the flight speed (leaving enough time between exposures) – so not tested yet.
As an in-App purchase you also can automatically do POI flights – this is very handy for these dense point clouds of single objects and its not so straight forward to do this in manually POI mode as part of the DJI GO software (though also possible).
DJI GS Pro however has some strange ways to handle waypoints when you use the hover method but once you understand where the problem is (the number of waypoints is restricted to 99) – it works nicely. DJI GS Pro also comes with different modi – “Virtual Fence” is very nice for training and restricting the flight space, “3D-Map Area” is for mapping of larger areas and “3D Map POI” is for these POI flights where you want to map 3D object structures and where you have enough space between objects to create some kind of circumnavigation.
The full manual goes here: https://dl.djicdn.com/downloads/groundstation_pro/20170831/GS_Pro_User_Manual_EN_V1.8.pdf
Some shots from the Kuckenburg flight campaign with 500 DNG shots and approx. 50Mio and 80Mio points in different dense point cloud calculations with Agisoft. As we don’t have a SAPOS subscription for “Sachsen-Anhalt” no DGPS points were measured. However some fixed points from the FSU Jena excavation team will be used.
